| Frame | OCLV Mountain Carbon, IsoSpeed, tapered head tube, Knock Block, internal control routing, balanced post mount brake, Boost148 |
|---|---|
| Fork | RockShox Recon Gold RL, DebonAir spring, Motion Control damper, remote lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 100mm travel |
| Suspension lever | RockShox OneLoc Sprint |
| Max compatible fork travel | 120mm (533mm axle-to-crown) |
| Wheel front | Bontrager Kovee Comp 23, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29'' |
|---|---|
| Wheel rear | Bontrager Kovee Comp 23, Tubeless Ready, Shimano Microspline freehub, Rapid Drive 108, Boost148, 29'' |
| Skewer rear | Bontrager Switch thru axle, removable lever |
| Tire | Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.20'' |
| Tire part | Bontrager TLR sealant, 6oz |
| Rim strip | Bontrager TLR |
| Max tire size | Frame: 29x2.40", Fork: See manufacturer |
| Shifter | Shimano SLX M7100, 12 speed |
|---|---|
| Rear derailleur | Shimano XT M8100, long cage |
| *Crank |
Size:
S Shimano MT611, 30T steel ring, alloy spider, 52mm chainline, 170mm length |
|
Size:
M , ML , L , XL , XXL Shimano MT611, 30T steel ring, alloy spider, 52mm chainline, 175mm length |
|
| Bottom bracket | Shimano MT500, 92mm, PressFit |
| Cassette | Shimano SLX M7100, 10-51T, 12 speed |
| Chain | Shimano Deore M6100, 12 speed |
| Max chainring size | 1x: 36T, min 30T |
| Saddle | Bontrager Arvada, hollow chromoly rails, 138mm width |
|---|---|
| *Seatpost |
Size:
S Bontrager Comp, 6061 alloy, 31.6mm, 8mm offset, 330mm length |
|
Size:
M , ML , L , XL , XXL Bontrager Comp, 6061 alloy, 31.6mm, 8mm offset, 400mm length |
|
| *Handlebar |
Size:
S , M , ML Bontrager Comp, alloy, 31.8mm, 5mm rise, 720mm width |
|
Size:
L , XL Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width |
|
|
Size:
XXL Bontrager Line, alloy, 35mm, 15mm rise, 750mm width |
|
| Grips | Bontrager XR Trail Elite, alloy lock-on |
| *Stem |
Size:
S , M Bontrager Rhythm Comp, 31.8mm, 0 degree, 60mm length |
|
Size:
ML Bontrager Rhythm Comp, 31.8mm, 0 degree, 70mm length |
|
|
Size:
L , XL Bontrager Rhythm Comp, 31.8mm, 0 degree, 80mm length |
|
|
Size:
XXL Bontrager Elite, 35mm, 0 degree, 90mm length |
|
| Headset | Knock Block Integrated, 62-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom |
| Brake | Shimano hydraulic disc, MT4100 lever, MT410 caliper |
| *Brake rotor |
Size:
S , M , ML , L , XL , XXL Shimano RT56, 6-bolt, 180mm |
|
Size:
S , M , ML , L , XL , XXL Shimano RT56, 6-bolt, 160mm |
|
| Rotor size | Max brake rotor sizes - Frame: 180mm, Fork: see fork manufacturer |
| Weight | M - 11.43 kg / 25.21 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
